Montigo PL Series


The PL Series by Montigo is a single-sided direct-vent gas fireplace line with three size options. The PL Series features a contemporary, rectangular fireplace shape with a clean face metal trim that surrounds the glass viewing area. Non-combustible finishing materials can be installed right to the edge of the metal trim, resulting in a versatile finished look that is easily-integrated into any space. The PL Series uses buried linear burner technology which provides more control over the burn pattern (as the decorative media can be placed over top of the burn to variegate the flame), and flame height adjustment. You can choose from interior media options of ceramic driftwood logs, river rock and fireglass. Optional upgrades available for the PL Series include reflective porcelain interior panels and a variable speed fan.


  • Buried linear burner technology and adjustable flame height

  • Finishing materials can be installed to edge of the clean face metal trim

  • Operated using a thermostatic remote control that allows the user to regulate flame size and heat output

  • Electronic ignition with battery back-up for power outages

  • Safety barrier screen is included**

  • Cool-Pak Glass (cool glass barrier) compatible

  • Fireplaces can be top or rear-vented

  • Power-vent compatible

  • Ceramic driftwood log, river rock and fireglass media options



PL 38

Required opening: 37-3/4" w x 35-1/4" h x 20-1/8" d

Fire viewing: 35-1/4" w x 18" h
Max. square footage heated: 500 ft. sq. (25,000 BTUs/h.)*

PL 42

Required opening: 42" w x 37" h x 22-5/8" d

Fire viewing: 39"-1/2" w x 19" h
Max. square footage heated: 640 ft. sq. (32,000 BTUs/h.)

PL 52

Required opening: 52" w x 37-1/2" h x 25" d

Fire viewing: 47" w x 21" h
Max. square footage heated: 800 ft. sq. (40,000 BTUs/h.)

* This is an approximate measure that may be affected by several variables.

** As per CSA regulations implemented in 2015, all fireplaces with a sealed glass front are installed with a safety screen if it has been determined that the glass surface temperature exceeds 172° F while the unit is fired.



Montigo has always been an innovator in the fireplace industry. They began manufacturing open concept b-vented gas fireplaces in 1985, later adopting a new fireplace design concept that would quickly envelop the entire heating industry – direct-vent gas fireplaces.
A proudly Canadian company, Montigo has maintained their manufacturing operations in the cities of Langley and Surrey, BC. Mutually inspired towards excellence and integrity in fireplace design, The Fireplace Specialist has been representing, selling and installing Montigo fireplaces since their entry into the Canadian fireplace market. Today we offer our clients Montigo's full range of residential direct-vent gas fireplaces and gas inserts; residential and commercial power-vented gas fireplaces; double-wall insulated b-vent gas fireplaces; outdoor ventless gas fireplaces; in-line and external power-vent systems and Cool-Pak Glass (cool glass barrier) safety systems. The Fireplace Specialist and Montigo often collaborate to develop custom fireplace designs for both residential and commercial spaces.
